| 輸入電壓 |
100 – 120 V (50 – 60 Hz) |
| 消耗功率 |
＜0.5 W standby
60 W device in operation |
| 輸入端子 |
2 × balanced (XLR)
3 × unbalanced (RCA)
1 × Phono-MC (optional) |
| 輸入阻抗 |
2 kΩ balanced (XLR)
47 kΩ unbalanced(RCA)
10 – 1000 Ω (adjustable) |
| 輸出端子 |
1 × balanced (XLR)
1 × unbalanced (RCA) |
| 頻率響應 (– 3 dB) |
0 – 1 MHz |
| 總諧波失真率 |
＜0.00009% (20 Hz – 20 kHz) |
| 訊噪比 |
＞140 dB |
| 聲道分離度 |
＞110 dB |
| 增益 |
+ 9.5 dB balanced (XLR)
+ 3.5 dB unbalanced (RCA)
+ 54/60 dB Phono-MC unbalanced (optional)
plus gain adaption + 3/+ 6/+ 9 dB |
| 音量控制 |
0 to – 79 dB in 1 dB steps |
| 輸出阻抗 |
2 Ω balanced (XLR)
2 Ω unbalanced (RCA) |
| 輸出電壓 |
16 VRMS balanced (XLR)
8 VRMS unbalanced (RCA) |
| 最大輸出電流 |
1 A (limited by protection circuit) |
| 尺寸 |
480 × 167 × 450 mm (W x H x D) |
| 重量 |
approx. 30 kg |
| LINK (remote turn-on) |
12 V control signal |
