| 輸入電壓 |
100 – 120 V (50 – 60 Hz) |
| 消耗功率 |
＜0.5 W standby
100 W device in operation |
| 輸入端子 |
2 × balanced (XLR)
2 × unbalanced (RCA) |
| 輸入阻抗 |
820 kΩ balanced (XLR)
47 kΩ unbalanced(RCA) |
| 輸出端子 |
1 × balanced (XLR)
1 × unbalanced (RCA) |
| 頻率響應 (– 3 dB) |
0 – 2 MHz |
| 總諧波失真 |
＜0.00009% (20 Hz – 20 kHz) |
| 訊噪比 |
120 dB |
| 聲道分離度 |
130 dB @ 1 kHz |
| 最大增益 |
+ 15 dB |
| 音量控制範圍 |
+ 15 dB to – 79 dB in 1 dB steps |
| 輸出阻抗 |
10 Ω balanced (XLR)
10 Ω unbalanced (RCA) |
| 輸出電壓 |
16 VRMS balanced (XLR)
8 VRMS unbalanced (RCA) |
| 最大輸出電流 |
0.2 A (limited) |
| 尺寸 |
442 × 143 × 448 mm (W x H x D) |
| 重量 |
approx. 20 kg |
| LINK (remote turn-on) |
12 V control signal |
