| 輸入電壓 |
220 – 240 V (50 – 60 Hz)
100 – 120 V (50 – 60 Hz) |
| 消耗功率 |
Under 0.5 W, Standby
~ 30 W, ON |
| 類比輸入 |
2 × balanced (XLR)
2 × unbalanced (RCA)
1 × Phono MC (optional) |
| 輸入阻抗 |
3 kΩ balanced (XLR)
3 kΩ unbalanced (RCA)
10-1260 Ω phono (RCA) |
| 數位輸入 (選配l) |
1 × AES/EBU, 1 × SPDIF, 1 × USB, 1 × Network |
| 增益 |
– 79 to + 10 dB |
| 頻率響應 (– 3 dB) |
0 – 800 kHz |
| 總諧波失真 |
＜ 0.0001% |
| 噪訊比 |
> 120 dB |
| 最大輸出電流 (峰值) |
＞ 0.2 A |
| 聲道分離度 |
> 120 dB |
| 輸出阻抗 |
10 Ω balanced (XLR)
10 Ω unbalanced (RCA) |
| 尺寸 |
430 x 350 x 142 mm (WxDxH)) |
| 重量 |
~15 kg |
| LINK (remote turn-on) |
2 x phone jack (3.5mm) |
